These designs are AI-assisted 3D visualisations
Stand Dünyası can manufacture more than 90% of what you see here in its own workshop. Some details an AI cannot foresee may not be reproducible exactly as shown. When you contact us about a design you like, we tell you plainly which parts can be built as drawn and which need adapting — we do not make a promise we cannot keep.
Specification
| Stand type | Crowned island kiosk |
|---|---|
| Placement | Island: in the open floor of the mall concourse, open to customers on all four sides. |
| Dimensions | 300 × 260 cm (9 ft 10.1 in × 8 ft 6.4 in), overall height 220 cm (7 ft 2.6 in), crown 20 cm (7.9 in) |
| Sector | Reusable water bottles, insulated tumblers, lids and straws, with laser name engraving |
| Brand shown | HYDRELLO — a fictional brand created for this concept |
The story
HYDRELLO sells reusable bottles and tumblers and puts your name on them while you wait. The stand is aqua, coral and brushed steel, as fresh as a glass of cold water.
The island is open on all four sides: bottles on one side, tumblers on another, a live laser engraver on the third and payment on the fourth. The aqua crown is 20 cm high, stays within the 220 cm limit and repeats the logo on every side, while slim steel columns keep the stand light.
Manufacturing and materials
- Body: 18 mm MDF in white high-gloss and aqua lacquer.
- Tops: 12 mm white solid-surface, water-resistant.
- Risers: 10 mm white acrylic steps with anti-slip strips and integrated LED.
- Columns: Ø 100 mm stainless-steel tubes, brushed finish.
- Crown: 20 × 16 cm aluminium section, aqua lacquer, white acrylic letters, coral line inlay.
- Engraver: enclosed class-1 laser engraver with fume filter, fixed to the counter; dedicated 16 A line.
- Back graphic: backlit fabric print in an aluminium frame.
Final dimensions are confirmed by on-site measurement before production. Mall height limits, electrical supply and fire regulations are checked with the centre’s technical office at project stage.
