These designs are AI-assisted 3D visualisations
Stand Dünyası can manufacture more than 90% of what you see here in its own workshop. Some details an AI cannot foresee may not be reproducible exactly as shown. When you contact us about a design you like, we tell you plainly which parts can be built as drawn and which need adapting — we do not make a promise we cannot keep.
Specification
| Stand type | Counter-type island kiosk |
|---|---|
| Placement | Island: in the open floor of the mall concourse, open to customers on all four sides. |
| Dimensions | 380 × 240 cm (12 ft 5.6 in × 7 ft 10.5 in), counter 110 cm (3 ft 7.3 in), two towers 210 cm (6 ft 10.7 in) |
| Sector | Electric scooters, helmets, locks and spare parts |
| Brand shown | SCOOTRIX — a fictional brand created for this concept |
The story
SCOOTRIX sells electric scooters for city commuting, together with the helmets, locks and parts that go with them. The stand is a low U around a raised floor where three scooters stand folded on turntables, the way customers will carry them onto a tram or into an office.
Folding the scooters keeps every product below the 110 cm counter height, so the stand stays open and easy to see across. Two yellow towers of 60 × 15 × 210 cm at the back corners carry the brand and a scooter-wheel drawing, visible from both ends of the concourse.
Asphalt grey and signal yellow come from the street itself. The right side has no showcase, so it carries a skyline graphic that shows where the product is used.
Manufacturing and materials
- Counter body: 18 mm MDF, asphalt-grey matte lacquer with a light concrete texture.
- Display floor: plywood deck on a steel frame, 15 cm high, black ribbed rubber finish; three motorised turntables Ø 70 cm, 150 kg load each.
- Worktop: 12 mm black compact laminate, scratch-proof.
- Showcases: 8 mm tempered glass, lockable, 5000K LED.
- Graphics: UV print on aluminium composite panel with an anti-scuff laminate.
- Towers: steel frame, yellow lacquered MDF, bolted to the counter frame.
- Services: 16 A power line; charging point inside the back counter for demo scooters.
Final dimensions are confirmed by on-site measurement before production. Mall height limits, electrical supply and fire regulations are checked with the centre’s technical office at project stage.
