These designs are AI-assisted 3D visualisations
Stand Dünyası can manufacture more than 90% of what you see here in its own workshop. Some details an AI cannot foresee may not be reproducible exactly as shown. When you contact us about a design you like, we tell you plainly which parts can be built as drawn and which need adapting — we do not make a promise we cannot keep.
Specification
| Stand type | Counter-type island kiosk |
|---|---|
| Placement | Island: in the open floor of the mall concourse, open to customers on all four sides. |
| Dimensions | 320 × 220 cm (10 ft 6 in × 7 ft 2.6 in), counter 110 cm (3 ft 7.3 in), two towers 210 cm (6 ft 10.7 in) |
| Sector | Pizza by the slice: margherita, pepperoni, four cheese and vegetable, reheated to order |
| Brand shown | SLICETTA — a fictional brand created for this concept |
The story
SLICETTA sells pizza the fast way: by the slice, reheated in a hot deck oven in under two minutes. Six whole pizzas sit in a warm glass display at the front, so customers choose with their eyes, and a round porthole at the back shows the oven glowing red.
The oven is built into the counter under the worktop and has its own recirculating filter, so there is no hood and nothing above the 110 cm line except two slim black towers. They stand at the middle of the two short ends and face the long sides, so the logo is read by everyone walking along the concourse.
Tomato red, basil green and mozzarella white are the colours of the flag and of a margherita, with a black band that recalls the oven.
Manufacturing and materials
- Counter body: 18 mm moisture-resistant MDF, tomato-red lacquer; printed checked strip under a scratch-resistant laminate.
- Worktop: 12 mm white solid-surface on a 30 mm substrate, food-safe.
- Slice display: heated display case (+65 °C) with 8 mm sloped tempered glass flush with the worktop, 3000K LED.
- Oven: built-in ventless electric deck oven with integrated recirculating hood (catalytic converter and activated carbon); heat-resistant ceramic glass porthole.
- Hygiene: stainless hand-wash sink with hot water, fresh-water and grey-water tanks or mall connection through the plinth.
- Towers: steel frame, black lacquered MDF, red powder-coated edge profiles, printed acrylic illustration panels.
- Services: 32 A three-phase power line for the oven; hidden cable ducts.
Final dimensions are confirmed by on-site measurement before production. Mall height limits, electrical supply and fire regulations are checked with the centre’s technical office at project stage.
